How Long can Rubber Products be stored for?

How Long can Rubber Products be stored for?

Introduction

All rubber products have a weakness, whether it be temperature, exposure to sunlight, or another, and different rubber compounds have different weaknesses.

The simple answer to this question calls upon ISO 2230 which gives a good-but-broad answer through a simple framework

  1. Before you start, know which rubber you are looking at.
  2. Which group (A-C) does your rubber belong to
  3. What are the recommended storage times for that group
  4. What are the assumed storage conditions.

So, let's get started.

Rubber Groupings under ISO 2230

Group A rubber compounds include:

Common Rubber Compound Name Abbreviation for Compound  Chemical Name (ISO 1629)
Natural Rubber NR Natural Rubber
Polybutadiene BR Butadiene Rubber
Polyisoprene IR Isoprene Rubber Syntetic
SBR SBR Styrene-Butadiene Rubber
Polyurethane AU Polyester Urethane Rubber
Polyurethane EU Polyester Urethane Rubber



Group B rubber compounds include:

Common Rubber Compound Name Abbreviation for Compound  Chemical Name (ISO 1629)
Nitrile NBR Acrylonitrile-Butadiene Rubber
Carboxylated Rubber XNBR Carboxylic-Acrylonitrile-Butadiene Rubber
Hydrogenated Nitrile HNBR Hydrogenated NBR
Neoprene CR Chloroprene Rubber
Butyl IIR Isobutene-Isoprene Rubber
Bromobutyl BIIR Bromo- Isobutene-Isoprene Rubber
Chlorobutyl CIIR Chloro- Isobutene-Isoprene Rubber



Group C rubber compounds include:

 Common Rubber Compound Name Abbreviation for Compound  Chemical Name (ISO 1629)
Chlorinated Polyethylene CM Chloropolyethylene
EPM, EPR EPM Ethylene-Propylene Copolymer
EPDM EPDM Terpolymer of Ethylene, propylene and diene with
the residual unsaturated portion of the diene
Fluorocarbon FKM Rubber having the Fluoro, Perfluoroalkyl or Perfluoroalkoxy
substituent groups on the polymer (a common example is Viton)
Silicone Q Silicone Rubber
Fluorosilicone VMQ Silicone Rubber having both Methyl and Vinyl
substituent groups on the polymer chain



Recommendation storage limits for each Rubber Group

Once we know which group our rubber is in, we can look it up in the below table:

 Rubber Group Initial Storage Period Extension Storage Periods
Group A 5 years 2 years
Group B 7 years 3 years
Group C 10 years 5 years

The initial storage period is a given, if stored correctly.  At this point the products should be inspected.  If the parts look unchanged, then the extension period can be applied.

If your rubber is a blend of two different groups, use the shorter timescales, if applicable.

Rubber Storage Conditions

ISO 2230 specified the storage conditions for rubber products to ensure their longevity and to prevent deterioration.  These conditions include maintaining a cool, dry environment, protecting against light and UV radiation, and preventing exposure to ozone.

Specifically, storage temperatures should be below 25°C (preferably below 15°C), and relative humidity should be kept below 70% (65% for polyurethanes).  Additionally, products should be protected from direct sunlight, strong artificial light and ionising radiation.

Common Issues Faced with Rubber Storage

There are a few common issues we are asked about, and face internally with our own products:

  • What if I receive multiple batches at different times?  The answer to this one is that you can ask your supplier when different batches were cured/vulcanised.  If the dates are similar, then many companies will combine the storage and inspection cycles should date thresholds be met.  If the dates are notably different then the different batches should be kept separate.
  • My supplier cannot be specific about when my products were manufactured.  Suppliers should be able to tell you this information.  If they cannot, are you sure that they are manufacturing them rather than reselling them?
  • I am not sure what my rubber is, what should I do?  Ask your supplier, this information should be readily available.
  • I have received parts that were moulded a year ago.  What does that mean for my timelines?  In this case, you should knock off a year from the timeline.

Further Questions

If you have any questions relating to this topic, please feel free to contact us.
